BESCHIKBARE OPTIES
CHOOSE THE RIGHT SIZE
SECURITY AND FLEXIBILITY
Ottoo is the easiest and fastest-to-assemble cylinder that combines the flexibility of the modular system with the security of 8 active pins and the guarantee of Omec quality.
4 GOOD REASONS TO CHOOSE
Materials
Housing made of high-strength aluminium with ceramic patented coating to achieve the highest corrosion resistance and durability. Nickel-plated core for easy access to insert the key more smoothly and prevent breakage.
Sustainability
Tested and certified for 100,000 opening cycles.
Modular
Any size you need, simply with a screwdriver. Ottoo is available as an already assembled cylinder or as a cylinder that can be assembled on site, thanks to the quick and easy modular system that allows each cylinder to be assembled with just a screwdriver, for maximum flexibility and minimum inventory, even for special systems.
Security
Ottoo is the first cylinder with 8 active pins with additional protection of the modular patented system.
DRILL RESISTANT
3 tempered steel drill resistant pins.
8 ACTIVE PINs
8 active pins on two rows:
over 300.000 combinations.
SACRIFICIAL CUT
Anti-pick and anti-snap sacrificial cut on the cylinder body.
PICKLOCK RESISTANT
Stainless steel pins, springs and drivers.
PUSH RESISTANT
Self-lubricating steel 30° DIN cam.
Clutching version for emergency function.
EVEN MORE SECURE THE MODULAR VERSION
Patented system with tear resistant steel bar and connecting screws.
ALL VERSIONS
EVEN BETTER.
Ottoo is available with a satin-nickel coloured aluminum body and in a refined black finish.
The modular version offers the possibility of choosing the most aesthetically elegant solution in the same colour as the door profile directly on site: you just need to assemble the heads of the preferred colour.
The complete range always ready for installation
SERIES 320Double cylinder
SERIES 321Half cylinder
SERIES 322Double clutching cylinder
SERIES 323Double cylinder with knob
SERIES 324Half cylinder with knob
THE IDEAL SOLUTION FOR YOUR WORK
Modular, quick and secure
The modular system makes it possible to optimize warehouse stocks and immediately satisfy any requests from the customer, even on site.
Otto is the only cylinder with a patented system with fixing screws that reach the cylinder plug, for maximum tear resistance and maximum ease of assembly.
Any dimensions you need
Modular sizes starting from 30+30 mm for the double cylinder and from 30+10 mm for the half cylinder, with extensions of 5 – 10 – 15 – 20 mm, to satisfy any assembly needs in less than a minute, for profiles up to to 150 mm thick.
A case for all components
All the components for assembling the modular cylinder are supplied in a handy case, in order to be able to assemble cylinders suitable for any thickness of the door, directly on site.
All modules are pre-assembled and individually tested, for total quality guarantee.
CHOOSE THE RIGHT SIZE
Veiligheid en flexibiliteit
Ottoo is the easiest and fastest-to-assemble cylinder that combines the flexibility of the modular system with the security of 8 active pins and the guarantee of Omec quality.
4 GOOD REASONS TO CHOOSE
Materials
Housing made of high-strength aluminium with ceramic patented coating to achieve the highest corrosion resistance and durability. Nickel-plated core for easy access to insert the key more smoothly and prevent breakage.
Sustainability
Tested and certified for 100,000 opening cycles.
Modular
Any size you need, simply with a screwdriver. Ottoo is available as an already assembled cylinder or as a cylinder that can be assembled on site, thanks to the quick and easy modular system that allows each cylinder to be assembled with just a screwdriver, for maximum flexibility and minimum inventory, even for special systems.
Security
OTTOO is de eerste cilinder met 8 actieve pennen met extra bescherming van het modulaire gepatenteerde systeem.
Waar voor je geld
Verander elke functie in een voordeel voor je lezer.
Wijzig stijlen
Je kunt kleuren en achtergronden bewerken om objecten te markeren.
Voorbeeld iconen
Anti-pick and anti-snap sacrificial cut on the cylinder body.
THE KEY TO SUCCESS
Code
Indirect codification on the key head.
Reversibility
Flat silver-nickel reversible key with long neck compatible with security escutcheon.
Ergonomics
Ergonomic and removeable key cover interchangelable and available in many different colours.
Thickness 3 mm
For a higher resistance to breaking.
Pins levels
0,5 mm
For an higher security in combinations.
Temporary
key
Temporary key made of brass that gets disabled when the property key is inserted and turned.
Security
Over 300.000 different combinations.
Special keying systems
Special systems KA-MK-GMK-CL.
Up to 50.000 different cylinders opened with 1 master key.
Property card
Security card with code number to duplicate the key in maximum security, duplications allowed only from authorized dealers.
ALTERNATIEVE PRODUCTEN
Specifications
| Outside dimensions A (mm) | 30 or 35 or 40 or 45 or 50 or 55 or 60 or 65 or 70 or 75 or 80 or 85 or 90 or 95 or 100 or 110 or 120 or 130 or 140 or 150 |
| Inside dimensions B (mm) | 10 (half cylinder) or 30 or 35 or 40 or 45 or 50 or 55 or 60 or 65 or 70 or 75 or 80 or 85 or 90 or 95 or 100 or 110 or 120 or 130 or 140 or 150 |
| Additional options | Without or Knob or Emergency & Danger function |
| Colour | Nickel-plated or Black |
| Temporary construction site key | Without or With |
| Model | OMEC OTTOO |
| Certification | Safety certificate |
| Category | High security cylinder |
